Grooving Insert Lathe Slotted Blade H01 for Aluminium Cutting Turning Tool Blade

Home » Products » CNC Insert » For Aluminium » Grooving Insert Lathe Slotted Blade H01 for Aluminium Cutting Turning Tool Blade

Grooving Insert Lathe Slotted Blade H01 for Aluminium Cutting Turning Tool Blade

The MGMN H01 is a specific insert geometry primarily designed for grooving and cut-off operations. Here is a breakdown of its key features:

Geometry Code (MGMN): This ISO code defines the insert's shape and features.

M: Shape code for a diamond-shaped insert with a 30-degree acute angle, ideal for profiling and minimizing interference.

G: Tolerance class, indicating precise manufacturing dimensions.

M: Fixation type, signifying a clamp/pin hole pocket design for secure clamping.

N: Cutting edge preparation (e.g., a small chamfer/land) for improved edge strength.

Grade: H01: This is a specific carbide grade from the manufacturer, typically associated with high-performance multi-layer coatings (like AlTiN/TiSiN-based) designed for demanding applications in stainless steel, heat-resistant alloys, and other difficult-to-machine materials.

Typical Application: It is widely used for precision external grooving, face grooving (when mounted on specific toolholders), and parting off operations, especially where high cutting speeds and feed rates are required in challenging materials.

Availability:

Quantity:



Inquire Add to Basket

cutter cnc cutting machine cutting machine carbide cutter carbide insert Turning insert Turning tool insert Cutting tool turning tool carbide insert tool

Product Description

Technical and Application Overview of MGMN H01 Grooving Insert

1. Insert Identification & Design

The designation follows the standard ISO/ANSI system, breaking down as follows:

1)Shape & Style: The MGMN geometry is a positive-rake, single-sided insert. The acute 30-degree point angle provides excellent accessibility for intricate groove profiles and reduces cutting forces.

2)Clamping & Chipbreaker: The 'M' (Hole & Clamp) and 'N' (Chipbreaker Geometry) indicate a robust clamping system and an engineered chipbreaker design. This chipbreaker effectively controls chips in high-efficiency grooving, preventing clogging and improving surface finish.

2. Core Competence: Grade H01

This is the heart of the insert's performance. H01 typically represents:

1)Substrate: A fine-grained or ultra-fine-grained tungsten carbide substrate, offering an optimal balance of toughness and wear resistance.

2)Coating: A state-of-the-art PVD (Physical Vapor Deposition) multi-layer coating, often based on AlTiN (Aluminum Titanium Nitride) with enhancements like TiSiN.

3)Performance Profile: This coating provides exceptional heat resistance, oxidation resistance, and hardness at high temperatures. It excels in dry or near-dry machining and is specifically engineered for:

(1)Stainless Steels (e.g., 304, 316, 17-4PH)

(2)Heat-Resistant Superalloys (e.g., Inconel, Waspaloy, Titanium alloys)

(3)Hardened steels

3. Key Applications & Advantages

Applications:

1)External and internal precision grooving.

2)Parting-off / Cut-off operations from the bar stock.

3)Face grooving and trepanning when used with appropriate toolholders.

4)Light profiling and turning of shoulders.

Key Advantages:

1)High Productivity: Enables significantly higher cutting speeds and feed rates compared to conventional grades in tough materials.

2)Extended Tool Life: Superior wear resistance reduces downtime for insert changes.
